HDPE Unfilled
HDPE Unfilled Overview
What is the Material: HDPE Unfilled is a semi-crystalline material.
Key Material Features: This material is beneficial in applications requiring chemical resistance, impact strength, low moisture absorption, and the ability to retain properties at low temperatures.
Other Considerations: This material is rigid and has a lower impact strength as a result of that.
Physical
| Property | Value | Typical ASTM Test |
|---|---|---|
| Chemical Designation | (HDPE) High Density Polyethylene | |
| Trade Names (®, ™) | Tecafine, Corrtec Hitec, King KPC HDPE, Polystone G, Proteus | |
| Color | Natural, Various Colors | |
| Density (g/cm^3) | 0.95 | D 792 |
Mechanical
| Property | Value | Typical ASTM Test |
|---|---|---|
| Modulus of Elasticity (Tensile Test) (psi) | 140000 | D 638 |
| Tensile Strength at Yield (psi) | 3700 | D 638 |
| Elongation at Yield (%) | 9.8 | D 638 |
| Elongation at Break (%) | 100 | D 638 |
| Flexural Strength (psi) | 4000 | D 790 |
| Modulus of Elasticity (Flexural Test) (psi) | 140000 | D 790 |
| Compression Strength: 10% Strain (psi) | 4600 | D 695 |
| Compression Modulus (psi) | 100000 | D 695 |
| Impact Strength (Izod) (ft-lbs/in) | 1.94 | D 256 |
| Hardness (R) | 54 | D 785 |
| Hardness (D) | 65 | D 785 |
| Coefficient of Friction (Kinetic, 40 psi, 50 fpm) | 0.24 | D 3702 |
Thermal
| Property | Value | Typical ASTM Test |
|---|---|---|
| Vicat Softening Point (°F) | 261 | |
| Melting Point (°F) | 268 | D 3418 |
| Deflection Temperature (°F) (264 psi) | 165 | D 648 |
| Service Temperature Continuous (°F) | 180 | |
| Service Temperature Minimal (°F) | -103 | |
| Thermal Expansion (CLTE) (in/in/°F) | 6.00E-5 | D 696 |
Electrical
| Property | Value | Typical ASTM Test |
|---|---|---|
| Specific Surface Resistance (Ω/square) | 1.00E15 | D 257 |
| Dielectric Strength (V/mil) | 450 | D 149 |
| Dielectric Constant (1MHz) | 2.3 | D 150 |
Other
| Property | Value | Typical ASTM Test |
|---|---|---|
| Moisture Absorption (%) (24 Hours) | 0.01 | D 570 |
| Flammability | HB |
The data stated are typical values intended for reference and comparison purposes only. The data should not be used as a basis for design specifications or quality control. The information is provided as a guide to the best of our knowledge and given without obligation or liability. Testing under individual application circumstances is recommended.
