Polypropylene Copolymer
Overview
What is the Material: Polypropylene Copolymer is a semi-crystalline material.
Key Material Features: This material is beneficial in applications requiring chemical resistance, low moisture absorption, thermal and electrical properties, and low density.
Other Considerations: This material can be used in applications requiring lower temperatures than polypropylene homopolymer.
Physical
| Property | Value | Typical ASTM Test |
|---|---|---|
| Chemical Designation | (PP-C) Polypropylene Copolymer | |
| Trade Names (®, ™) | Tecafine, Polystone P | |
| Color | Natural | |
| Density (g/cm^3) | 0.91 | D 792 |
Mechanical
| Property | Value | Typical ASTM Test |
|---|---|---|
| Modulus of Elasticity (Tensile Test) (psi) | 152000 | D 638 |
| Tensile Strength at Yield (psi) | 3500 | D 638 |
| Elongation at Break (%) | 300 | D 638 |
| Flexural Strength (psi) | 5400 | D 790 |
| Modulus of Elasticity (Flexural Test) (psi) | 155000 | D 790 |
| Compression Strength: 10% Strain (psi) | 4400 | D 695 |
| Impact Strength (Izod) (ft-lbs/in) | 8 | D 256 |
| Hardness (R) | 102 | D 785 |
| Hardness (D) | 69 | D 785 |
| Hardness (M) | 95 | D 785 |
| Coefficient of Friction (Kinetic, 40 psi, 50 fpm) | 0.27 | D 3702 |
Thermal
| Property | Value | Typical ASTM Test |
|---|---|---|
| Melting Point (°F) | 323 | D 3418 |
| Deflection Temperature (°F) (264 psi) | 210 | D 648 |
| Service Temperature Continuous (°F) | 180 | |
| Thermal Expansion (CLTE) (in/in/°F) | 6.00E-5 | D 696 |
Electrical
| Property | Value | Typical ASTM Test |
|---|---|---|
| Volume Resistivity (Ω*cm) | 1.00E14 | D 257 |
| Dielectric Strength (V/mil) | 1140 | D 149 |
| Dielectric Constant (1MHz) | 2.5 | D 150 |
Other
| Property | Value | Typical ASTM Test |
|---|---|---|
| Moisture Absorption (%) (Saturated) | 0.01 | D 570 |
| Flammability | HB |
The data stated are typical values intended for reference and comparison purposes only. The data should not be used as a basis for design specifications or quality control. The information is provided as a guide to the best of our knowledge and given without obligation or liability. Testing under individual application circumstances is recommended.
